Project Case Study
Location: Stackhouse Bar and Grill, 13419 Olive Blvd, Chesterfield, MO 63017
We recently completed the installation of an Accurex exhaust hood system at Stackhouse Bar and Grill. This project involved integrating a robust kitchen ventilation system designed to handle the high demands of a commercial kitchen while ensuring safety and compliance with local regulations.
Key Deliverables
Planning and Preparation
- Site Evaluation: Assessed the kitchen layout to determine the optimal placement of the hood above cooking appliances, ensuring proper clearance and accessibility.
- Structural Preparation: Verified that the ceiling beams could support the weight of the exhaust hood, and reinforcements were added where necessary.
- Code Compliance: Ensured alignment with NFPA 96, local fire codes, and International Mechanical Code (IMC) standards.
Installation Process
1. Hood Mounting
- Mounted the Accurex hood using heavy-duty hanger brackets and threaded rods. Alignment was verified with plumb bobs to ensure level placement, critical for efficient grease drainage.
2. Ductwork Integration
- Exhaust Ducts: Installed liquid-tight, continuously welded stainless-steel ducts to channel grease-laden air safely to the exterior.
- Roof Connection: Secured the duct system to the roof curb using approved caulk and sealing materials, ensuring airtight and weather-resistant connections.
3. Ventilation Components
- Exhaust Fan: Mounted a UL-listed exhaust fan designed for grease-laden air on the roof, connected to the hood and interlocked with the kitchen equipment.
- Make-Up Air System: Installed to provide balanced airflow, preventing negative pressure in the kitchen.
4. Fire Suppression System
- Integrated an automatic fire suppression system within the hood, compliant with Type I hood standards, with nozzles strategically positioned to cover all cooking equipment.
5. Electrical Connections
- Wired the hood’s integrated lighting and control systems, including thermal switches and a user-friendly control panel.
6. Final Adjustments
- Installed grease filters and shatterproof light fixtures within the hood.
- Conducted airflow testing and balancing to optimize ventilation and verify compliance with specifications.
Outcome
The new Accurex exhaust hood system enhanced the kitchen’s air quality and safety while meeting all regulatory standards. The system’s durable and efficient design ensures Stackhouse Bar and Grill can maintain a clean and comfortable environment for staff and patrons.
